Опис

• Camera
• Image Sensor1/2.9″ Progressive Scan CMOS
• Min. Illumination Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR
• Shutter Speed 1/3 s to 1/100,000 s
• Slow Shutter Yes
• Day & Night IR Cut Filter
• Wide Dynamic Range120 dB
• Angle Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
• DNR3D DNR

• Lens
• Lens 2.8/4 mm
• Aperture F2.0
• FOV

  2.8 mm, horizontal FOV: 97°, vertical FOV: 67°, diagonal FOV: 121°

  4 mm, horizontal FOV: 78°, vertical FOV: 53°, diagonal FOV: 98°

• Lens Mount M12

• Illuminator
• IR Range 10 m
• Wavelength 850 nm

• PIR
• PIR Angle Horizontal: 90°, vertical: 80°
• PIR Range 10 m

• Video
• Max. Resolution 3072 × 2048
• Main Stream

  50Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656)

  25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

  60Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656)

  30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

• Sub Stream

  50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)

  60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)

• Third Stream

  50Hz: 25 fps (1280 × 720, 640 × 360, 352 × 288)

  60Hz: 30 fps (1280 × 720, 640 × 360, 352 × 240)

• Video Compression

  Main stream: H.265/H.264

  Sub-stream: H.265/H.264/MJPEG

  Third stream: H.265/H.264

• H.264 Type Main Profile/High Profile
• H.265 Type Main Profile
• Video Bit Rate32 Kbps to 16 Mbps
• SVC  Support H.264 and H.265 encoding

• Audio
• Environment Noise Filtering Yes
• Audio Sampling Rate 16 kHz

• Image
• Image Enhancement BLC/3D DNR/HLC
• Day/Night Switch Day/Night/Auto/Schedule

• Wi-Fi
• Frequency 2.412 GHz to 2.4835 GHz
• Channel Bandwidth 20/40 MHz
• Security WPA, WPA2
• Transfer Rate

  11b: 11 Mbps

  11g: 54 Mbps

  11n: up to 150 Mbps

• Wireless Range50 m
• Wireless Standards IEEE 802.11b/g/n

• Network
• Network Storage Support Micro SD/SDHC/SDXC card (128 GB), local storage and NAS (NFS, SMB/CIFS), ANR
• Simultaneous Live View Up to 6 channels
• User/Host Up to 32 users. 3 levels: administrator, operator and user
• Alarm Trigger Motion detection, video tampering, network disconnected, IP address conflict, HDD full, HDD error, PIR, illegal login

• Interface
• Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port
• Audio 1 built-in mic, 1 built-in speaker, mono sound
• On-Board Storage Built-in microSD/SDHC/SDXC slot, up to 128 GB

• Compression Standard
• H.264+ Main stream supports
• H.265+ Main stream supports

• Smart Feature-Set
• Face Detection Yes

• General
• Reset Yes
• Startup And Operating Conditions-10 °C to +40 °C (14 °F to +104 °F), humidity 95% or less (non-condensing)
• Power Supply12 VDC ± 25%, PoE (802.3af, class 3)
• Power Consumption And Current12 VDC, 0.5 A, max. 6 W, Ø5.5 mm coaxial plug power; PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 7 W
• Material Plastic
• Dimensions 102.8 mm × 65.2 mm × 32.6 mm (4.1″ × 2.6″ × 1.3″)
• Weight Camera: Approx. 128 g (0.3 lb.)
